Occupying and Connecting. Frei Otto.

Although the book was published in 2009, the origin of this publication dates back to the year 1964, from an investigation about “Shorter paths between two points” made by Frei Otto at the Institut für leichte Flächentragwerke in Stuttgart. This work was followed by others about networks and reticles in nature “Wide span two dimensional frameworks; 1970-1985” and “Natural structures“. The research carried out by Frei Otto is of clear interdisciplinary vocation, as a result of collaborations with biologists such as Ulrich Kull and Johann Gerhard Helmcke, as well as being focused on topology, mathematics or self-organized systems.

occupying and connecting 107B

Self-organization.

Otto, as Heinz Von Foerster already did, designs an experimental apparatus with floating magnetized pins that generates a self-organized system through repulsion and attraction.

occupying and connecting 16c

occupying and connecting 16d

The book is not presented as a finished investigation but as the germ of different ways to explore. It is a work on occupation processes (settlements, cities, urban planning) and connection processes (communications, infrastructures), but focused both from a morphogenetic and exclusively formal point of view. That is to say, Otto proposes a geometrical investigation on the evolution of the form, but deviating the look towards already existing processes in nature or in those others generated by the technology, like the experimental prototype devised by Otto that measures the relations between the occupation and the distance between objects. Only the last pages of the book are devoted to how these evolutionary patterns can be applied or transferred to urban growth or development.

This look was not new in Frei Otto. A work similar to this one but carried out from a point structural point of view can be found in “Finding Forms. Towards and Architecture of the Minimal” by OTTO, Frei and RASCH, Bodo.The methodology of the research is very clear and systematic, and is carried out from the individual and simple to the collective and complex. Occupation systems are analyzed first on points, lines and surfaces to subsequently evolve into meshes or grids, both static and flexible. The final objective is to provide architects and urban designers self-organized systems for human settlements.

occuponig and connecting p36-2b

Identity-Clusters/Multi-scalar-Flexibility

Finalist entry by nodo17 for Changdong-Sanggye Start-up and Culture Industry Complex International Competition in Seoul, South Korea.

2 retocada

To enhance identity and flexibility to future developers and owners, the system is fractally fragmented according to programmatic scales and clusters. Although the Start-up and Culture complex is a big scale project we do not want to lose the feeling of identity of its users. Each housing unit is part of a small cluster of houses, built with prefabricated CLT (Cross Laminated Timber) structures supported over concrete slabs. These collective housing groups range from two story up to five story floors This means clusters ranging from 20 to 80 homes. In turn, the campus in the sky fragments the five towers of 33 stories in smaller buildings ranging from 4 to 9 floors. Next scale level corresponds to each one of the towers and following level is the whole building. Likewise, the proposal is part of a bigger structure of pedestrian connections from Changdong Station to Seoul Arena. Ultimately our proposal is a multi-scalar system based on identity, knowledge transfer and time evolution.

Changdong_Culture_Complex_International_Competition.indd

Time evolution.

To allow and enhance interior future transformation, upload and download big products and furniture from start-up companies, an open forklift / lifting platform of 3×7 m. is located in one of the exterior sides of the core. For this reason, offices and apartments are built with prefabricated lightweight wooden structures that could be easily assembled and disassembled. A loading dock is located in level B1 and directly connected to forklift. Loading dock is formed by parking space for medium size trucks, manoeuvre area and storage material area close to lifting platform. For this reason level B1 has a 4,5 m. gauge.

Future transformation is synchronized with building life and activities in order to avoid or minimize as much as possible any conflict. In this regard, new construction work in plots in the sky will be developed without affecting close neighbours. Trucks will park in level B1 close to corresponding tower for unloading materials and construction systems. From storage area all material will be transport to plots in the sky, through the lifting platform. Then, construction work will be executed with prefabricated systems and without requiring any amount of water.

This system for uploading and downloading is suitable not only for construction work but also for moving products, goods and furniture through the whole Start-up and Culture Industry Complex.

Changdong_Culture_Complex_International_Competition.indd

For more information visit: http://www.nodo17.com/changdong-sanggye-start-up-and-culture-industry-complex
